Home > Products > Double Deck > Double Deck Metal glazed Aluminum Roofing equipment

Double Deck Metal glazed Aluminum Roofing equipment

  • Double Deck Metal glazed Aluminum Roofing equipment
  • Double Deck Metal glazed Aluminum Roofing equipment
  • Double Deck Metal glazed Aluminum Roofing equipment
  • Double Deck Metal glazed Aluminum Roofing equipment

Double Deck Metal glazed Aluminum Roofing equipment

    Payment Type: L/C,T/T
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days
    Packaging: nude
    Productivity: 30sets/month
    Brand: DiXin
    Transportation: Ocean
    Place of Origin: HeBei,China
    Supply Ability: 30sets/month
    Certificate: ISO
    HS Code: 84552210
    Port: TianJin Port

Basic Info

Model No.: DOUBLE LAYER ROOF FORMING MACHINE

Product Description

Double Deck Metal glazed Aluminum Roofing equipment


Specifications for Roofing Sheet Glazed Tile and IBR Trapezoidal Iron Sheet Double Layer Roll Forming Making Machine
coil material
type
Colored Steel Plate, Galvanized Board, Aluminum Plate
width
1000mm/1200mm/1250mm (according to customer requirements and profile drawing)
thickness
0.3-0.8mm
manual decoiler
inside diameter
500-508mm
coil width
1300mm
coil load
5T
forming device
shaft material
45#steel-high quality steel, diameter 70 mm
roller material
45# steel with chrome coating
roller station
depends on final design
Main frame


300 H steel
chain transport
1"
board thickness
16mm
weight
around 3.5T(depends on final design)
dimension
6500mm*1300mm*1200mm(depends on final design)
control system
PLC control system
total power
4+4kw (depends on final design)
voltage
380V, 50HZ, 3 phascs or as your need
productivity
10-15m/min(depends on final design)

Products show




Product Application

The roll forming machine is for steel sheet or aluminum sheet. It can form the sheet according to customer`s requirement.It is a new type of energy - saving and high -effective producing equipment for steel roof or wall panel.And it has many advantages, like high forming speed, stable and easy operation. The finished product can use in various industrial plants, villages, warehouses, supermarkets, hotels, exhibition, family construction, shopping malls shutter doors and etc.


Our main production machines have follows:
corrugated roof roll forming machine;
IBR roof roll forming machine;
Glazed tile roll forming machine;
Double Layer Roll Forming Machine;
Roof Ridge Roll Forming Machine;
Floor Deck Roll Forming Machine;
Trapezoid Roof Roll Forming Machine;
Roof & Wall Roll Forming Machine;
Color stone coated Roof Tile machiney;
C/Z/U Purlin Roll Forming Machine;
Highway Guardrail Roll forming machine;
Shutter Door & Door Frame Roll Forming Machine;
Cutting&Bending&Slitting Machine and so on .

01


Packaging Details --.

1.Tighten to container with steel wire rope and welded angel iron.

2.Main forming machine and unciler is naked (if you need we can also packed with water-proof plastic)

3 .Roll forming machine PLC control system and moter pump are packed with water-proof plastic coveragePortTianjinLead

Time :30 days after your pre-deposit


About us

Cangzhou Dixin Roll Forming Machine Co.,Ltd,Our company is the professional and leading manufacture,can manufacture ,design,installation and debug various roll forming machines and metal processing sheet equipments ,which produce metal roof wall panel,glazed roof tile , CZ steel purlin,floor desking,roof ridge cap,sandwich panel ,roof rtruss,shutter panel,shutter slat,door frame, guardrail ,and metal sheet uncoiler ,bending ,slitting,cutting,flattening,punching,crimpingl. especially can design machine according to customer's request.

OUR SERVICE

1. we can produce the special machine,send your drawing to us,we can design for you.

2. if you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.

3. we provide a one year warranty and lifelong technical support, we can send our technicians to you to give you on-site training.

The training period would be for no more than one week with the customer paying for the visa, return ticket, food, accommodations and a daily wage of US100.

4. engineers available to service machinery overseas.

5. if you come to visit our factory,we can book the room for you, car pick up to send.

Thanks for visiting our products, if you have interest, pls leave your message, or you can contact us, special design is available!
